Build System Architecture

Overview

The Hakka JSON build system uses CMake 3.20+ with a modular architecture designed for cross-platform compatibility (Linux, macOS, Windows). The system supports both static and shared library builds, optional features, and comprehensive testing infrastructure.

Distribution Methods:

  • Conan Package Manager: Pre-built binaries with dependency management (recommended)
  • Source Build: Direct CMake builds for development and customization

Core Philosophy:

  • Explicit source lists (no globbing for reliability)
  • Optional system dependencies with automatic fallback
  • Platform-specific optimizations
  • Strict compiler warnings with sanitizers in debug mode

Package Distribution Architecture

Conan Package Structure

Package Metadata:

Name:           hakka_json
Version:        1.0.0
License:        BSL-1.0 OR BSD-3-Clause
Package Type:   library (static by default)
Settings:       os, compiler, build_type, arch
Options:        shared=[True, False], fPIC=[True, False]

Dependency Graph:

hakka_json/1.0.0
├── nlohmann_json/3.12.0 (PUBLIC, header-only)
├── tl-expected/1.1.0 (PUBLIC, header-only)
└── ICU (PRIVATE, statically bundled)
    ├── libicudata.a  (32MB Unicode data)
    ├── libicui18n.a  (17MB internationalization)
    ├── libicuuc.a    (6.4MB common utilities)
    ├── libicuio.a    (113KB I/O streams)
    └── libicutu.a    (820KB tools utilities)

Package Contents:

package/
├── include/              (22 public headers)
│   ├── hakka_json_*.hpp
│   ├── handles/*.hpp
│   └── hakka_json_enum.h
├── lib/                  (libraries)
│   ├── libhakka_json_core.a      (1.4MB - core C++ library)
│   ├── libhakka_json.so          (37MB - C API shared library)
│   ├── libicudata.a              (32MB - bundled ICU)
│   ├── libicui18n.a              (17MB - bundled ICU)
│   ├── libicuuc.a                (6.4MB - bundled ICU)
│   ├── libicuio.a                (113KB - bundled ICU)
│   └── libicutu.a                (820KB - bundled ICU)
└── licenses/             (license files)
    ├── LICENSE
    ├── LICENSE-BSD
    └── LICENSE-BOOST

Critical Design Decision - ICU Static Linking:

  • ICU is statically bundled within the Conan package
  • All ICU libraries (~56MB total) are included in the package
  • Consumers automatically link against bundled ICU libraries
  • No external ICU dependency required on consumer systems
  • Ensures consistent Unicode behavior across platforms

Package Info (CMake Integration):

# Conan generates these targets:
HakkaJson::core

# Link order (automatic via Conan):
hakka_json_core → icutu → icui18n → icuio → icuuc → icudata

# System libraries (32-bit platforms):
atomic (GCC/Clang on x86, armv7)

Compiler Requirements:

Minimum Versions:
  GCC:         11
  Clang:       15
  AppleClang:  14
  MSVC:        193 (Visual Studio 2022 17.3)

C++ Standard:  C++23 (required, no fallback)

Architectural View

CMake Target Architecture

graph TB
    subgraph Project["CMake Project: hakka_json v1.0.0<br/>Languages: C++23 + C"]
        Interface["INTERFACE Libraries<br/>hakka_json::compiler_options"]
        Config["Build Configuration<br/>Dependencies.cmake<br/>CompilerOptions.cmake<br/>ICU.cmake"]
    end

    subgraph Targets["Build Targets"]
        direction LR
        Static["STATIC Library<br/>hakka_json_core"]
        Shared["SHARED Library<br/>hakka_json (C API)"]
        Exec["EXECUTABLE Targets<br/>Core Tests<br/>CAPI Tests<br/>Perf Tests<br/>Draft Tool"]
        Ext["EXTERNAL Projects<br/>icu_project"]
    end

    subgraph Dependencies["Target Dependency Graph"]
        direction TB
        Core["hakka_json_core (STATIC)<br/>PUBLIC: nlohmann_json, tl::expected<br/>PRIVATE: ICU, atomic, compiler_options, TBB"]
        CApi["hakka_json (SHARED - C API)<br/>PRIVATE: hakka_json_core, ICU, compiler_options"]
        Tests["Test Executables<br/>PRIVATE: core/capi, GTest, compiler_options"]
    end

    Project --> Targets
    Config --> Targets
    Interface -.-> Static
    Interface -.-> Shared
    Interface -.-> Exec

    Static --> Core
    Shared --> CApi
    Exec --> Tests

    Core --> CApi
    Core --> Tests
    CApi -.-> Tests

    Ext -.-> Static
    Ext -.-> Shared

    style Project fill:#e1f5ff
    style Targets fill:#fff4e1
    style Dependencies fill:#f0f0f0
    style Static fill:#90EE90
    style Shared fill:#FFB6C1
    style Exec fill:#DDA0DD
    style Ext fill:#F0E68C

Build Targets

Primary Targets

Target Name Type Output Purpose
hakka_json_core STATIC libhakka_json_core.{a,lib} Core C++ library
hakka_json SHARED libhakka_json.{so,dll,dylib} C API wrapper
hakka_json::compiler_options INTERFACE (none) Compiler configuration

External Project Targets

Target Name Type Purpose
icu_project ExternalProject Build ICU from source
icu_project_libs CUSTOM Dependency aggregator for ICU libraries
icu{i18n,uc,data,io,tu} IMPORTED STATIC ICU library components (Unix)
icu{in,uc,dt,io,tu} IMPORTED STATIC ICU library components (Windows)

Test Targets

Core Tests (8 executables):

t_array, t_bool, t_float, t_int, t_invalid, t_null, t_object, t_string

C API Tests (4 executables):

capi_array, capi_object, capi_primitive, capi_complex

Performance Tests:

handle_perf_benchmark

Utility Targets:

draft (test/development executable)

Component Architecture

Static Library Component (hakka_json_core)

CMake Properties:

TYPE:                    STATIC_LIBRARY
POSITION_INDEPENDENT_CODE: ON
LANGUAGE:                CXX (C++23)
NAMESPACE:               hakka_json::core

Link Interface:

PUBLIC DEPENDENCIES:
  - nlohmann_json::nlohmann_json  (INTERFACE, header-only)
  - tl::expected                  (INTERFACE, header-only)

PRIVATE DEPENDENCIES:
  - ICU libraries (5 components, IMPORTED STATIC)
  - atomic (GCC only, system library)
  - TBB::tbb (optional, system library)
  - hakka_json::compiler_options (INTERFACE)

Include Directories:

PUBLIC (consumers inherit):
  $<BUILD_INTERFACE:${PROJECT_SOURCE_DIR}>
  $<BUILD_INTERFACE:${PROJECT_SOURCE_DIR}/include>
  $<INSTALL_INTERFACE:include>

PRIVATE (internal only):
  ${CMAKE_CURRENT_SOURCE_DIR}

Output Location: ${CMAKE_BINARY_DIR}/src/ -> ${PROJECT_SOURCE_DIR}/target/release/

Shared Library Component (hakka_json)

CMake Properties:

TYPE:                    SHARED_LIBRARY
POSITION_INDEPENDENT_CODE: ON
LANGUAGE:                CXX (C++23)
NAMESPACE:               hakka_json::capi
EXPORT_NAME:             hakka_json (no namespace for C API)

Link Interface:

PRIVATE DEPENDENCIES:
  - hakka_json::core (STATIC, brings transitive deps)
  - ICU libraries (re-linked for shared lib symbols)
  - hakka_json::compiler_options (INTERFACE)

PUBLIC DEPENDENCIES:
  (none - pure C interface)

Symbol Visibility:

Windows: DLL exports via __declspec(dllexport)
Unix:    Default visibility (all symbols exported)

Output Location: ${CMAKE_BINARY_DIR}/capi/ -> ${PROJECT_SOURCE_DIR}/target/release/

Interface Library Component (hakka_json::compiler_options)

CMake Properties:

TYPE:                    INTERFACE_LIBRARY
LANGUAGE:                (none - configuration only)
NAMESPACE:               hakka_json::compiler_options

Compile Options (generator expressions):

Warnings:
  $<$<OR:$<CXX_COMPILER_ID:GNU>,$<CXX_COMPILER_ID:Clang>>:-Wall -Wextra -Wpedantic -Werror>
  $<$<CXX_COMPILER_ID:MSVC>:/W4 /WX>

Debug Sanitizers:
  $<$<AND:$<CONFIG:Debug>,$<CXX_COMPILER_ID:GNU>>:-fsanitize=address,undefined,leak>
  $<$<AND:$<CONFIG:Debug>,$<CXX_COMPILER_ID:Clang>>:-fsanitize=address,undefined,leak>

Release Optimization:
  $<$<AND:$<CONFIG:Release>,$<OR:$<CXX_COMPILER_ID:GNU>,$<CXX_COMPILER_ID:Clang>>>:-O3>
  $<$<AND:$<CONFIG:Release>,$<CXX_COMPILER_ID:MSVC>>:/O2>

Compile Definitions:

$<$<CXX_COMPILER_ID:MSVC>:_CRT_SECURE_NO_WARNINGS _CTYPE_DISABLE_MACROS>
$<$<CONFIG:Release>:NDEBUG>

External Dependencies

Header-Only Dependencies (INTERFACE targets)

nlohmann_json (>=3.12.0):

TARGET TYPE:       INTERFACE (header-only)
ACQUISITION:       find_package() -> FetchContent
REPOSITORY:        https://github.com/nlohmann/json.git
TAG:               v3.12.0
LINK SCOPE:        PUBLIC (exposed in hakka_json_core API)
USAGE:             #include <nlohmann/json.hpp>

tl::expected (>=1.1.0):

TARGET TYPE:       INTERFACE (header-only)
ACQUISITION:       find_package() -> FetchContent
REPOSITORY:        https://github.com/TartanLlama/expected.git
TAG:               v1.1.0
LINK SCOPE:        PUBLIC (return types in hakka_json_core API)
USAGE:             tl::expected<T, E>

Compiled Dependencies (STATIC/SHARED targets)

ICU (International Components for Unicode):

TARGET TYPE:       IMPORTED STATIC (5 components)
ACQUISITION:       ICU_ROOT -> ExternalProject_Add (auto-build)
BUILD METHOD:      runConfigureICU (Unix) | MSBuild (Windows)
LINK SCOPE:        PRIVATE (never exposed in public API)
CONFIGURATION:     --enable-static --disable-renaming --with-data-packaging=static

UNIX TARGETS:
  - icui18n (internationalization)
  - icuuc   (common utilities)
  - icudata (Unicode data)
  - icuio   (I/O streams)
  - icutu   (tools utilities)

WINDOWS TARGETS:
  - icuin   (internationalization)
  - icuuc   (common utilities)
  - icudt   (Unicode data)
  - icuio   (I/O streams)
  - icutu   (tools utilities)

IMPORTED LOCATIONS:
  Unix:    ${ICU_LIB_DIR}/libicu{i18n,uc,data,io,tu}.{a,so}
  Windows: ${ICU_LIB_DIR}/icu{in,uc,dt,io,tu}.{lib,dll}

GoogleTest (>=1.15.2):

TARGET TYPE:       STATIC/SHARED (configuration-dependent)
ACQUISITION:       find_package() -> FetchContent
REPOSITORY:        https://github.com/google/googletest.git
TAG:               v1.15.2
LINK SCOPE:        PRIVATE (test executables only)
CONFIGURATION:     gtest_force_shared_crt=ON
TARGETS:           GTest::gtest_main, GTest::gmock_main

TBB (Threading Building Blocks) - Optional:

TARGET TYPE:       SHARED (system package)
ACQUISITION:       find_package(TBB REQUIRED)
ACTIVATION:        -DHAKKA_JSON_ENABLE_TBB=ON
LINK SCOPE:        PRIVATE (core library only)
PLATFORM:          x86_64 GCC only
DEFINES:           _ENABLE_STD_EXECUTION_POLICY

atomic (GCC runtime):

TARGET TYPE:       SYSTEM (implicit link)
PLATFORM:          GCC on all platforms
LINK SCOPE:        PRIVATE (core library only)
REASON:            64-bit atomic operations on 32-bit platforms

Test Target Architecture

Core Library Tests

Target Pattern: t_<component>

Target Type Dependencies Test Scope
t_array EXECUTABLE core + gtest_main Array container
t_bool EXECUTABLE core + gtest_main Boolean primitive
t_float EXECUTABLE core + gtest_main Float primitive
t_int EXECUTABLE core + gtest_main Integer primitive
t_invalid EXECUTABLE core + gtest_main Invalid type
t_null EXECUTABLE core + gtest_main Null primitive
t_object EXECUTABLE core + gtest_main Object container
t_string EXECUTABLE core + gtest_main String primitive

Link Interface (all test targets):

PRIVATE DEPENDENCIES:
  - hakka_json::core
  - hakka_json::compiler_options
  - GTest::gtest_main
  - GTest::gmock_main

Test Discovery: gtest_discover_tests() integration with CTest

C API Tests

Target Pattern: capi_<component>

Target Type Dependencies Test Scope
capi_array EXECUTABLE capi + gtest_main C API arrays
capi_object EXECUTABLE capi + gtest_main C API objects
capi_primitive EXECUTABLE capi + gtest_main C API primitives
capi_complex EXECUTABLE capi + gtest_main Complex nested structures

Link Interface (all CAPI test targets):

PRIVATE DEPENDENCIES:
  - hakka_json::capi
  - hakka_json::compiler_options
  - GTest::gtest_main
  - GTest::gmock_main

INCLUDE DIRECTORIES (additional):
  - ${PROJECT_SOURCE_DIR}/capi (internal headers)

Performance Benchmarks

Target: handle_perf_benchmark

TYPE:           EXECUTABLE
DEPENDENCIES:   hakka_json::core, compiler_options
COMPILE_OPTIONS:
  Unix:   -O2 -march=native
  MSVC:   /O2
INSTALL:        ${CMAKE_INSTALL_PREFIX}/bin/perf/

Custom Targets:

run_perf_benchmark:
  COMMAND: ${CMAKE_CURRENT_BINARY_DIR}/handle_perf_benchmark
  DEPENDS: handle_perf_benchmark

run_perf_stat (Linux only):
  COMMAND: bash run_perf_analysis.sh <benchmark> <output>
  DEPENDS: handle_perf_benchmark
  TOOL:    perf stat (performance counters)

Dependency Resolution Strategy

Two-Phase Lookup

1. System Package Discovery (if HAKKA_JSON_USE_SYSTEM_DEPS=ON)
   |
   v
   find_package(nlohmann_json 3.11 QUIET)
   |
   v
2. FetchContent Fallback (if not found)
   |
   v
   FetchContent_Declare(nlohmann_json
     GIT_REPOSITORY https://github.com/nlohmann/json.git
     GIT_TAG v3.12.0
   )
   FetchContent_MakeAvailable(nlohmann_json)

Rationale:

  • System preference: Respects distro packaging, reduces build time
  • Automatic fallback: Ensures builds succeed without manual intervention
  • Version pinning: FetchContent uses exact tags for reproducibility

ICU Special Handling

Function Wrapper (for PARENT_SCOPE export):

function(_setup_icu)
  include(${CMAKE_SOURCE_DIR}/cmake/ICU.cmake)
  set(ICU_INCLUDE_DIR ${ICU_INCLUDE_DIR} PARENT_SCOPE)
  set(ICU_LIB_DIR ${ICU_LIB_DIR} PARENT_SCOPE)
  # ... export all variables
endfunction()
_setup_icu()

Build Logic:

  1. Check ICU_ROOT for pre-installed ICU
  2. If not found, determine version:
  3. Use ICU_VERSION if specified
  4. Else fetch latest from GitHub API
  5. Download source tarball
  6. Build via ExternalProject_Add:
  7. Unix: Configure -> Make -> Install
  8. Windows: MSBuild solution
  9. Create IMPORTED targets with BUILD_BYPRODUCTS

Version Auto-Detection:

file(DOWNLOAD "https://api.github.com/repos/unicode-org/icu/releases/latest" ...)
string(REGEX MATCH "\"tag_name\": \"([^\"]+)\"" ...)
# Converts: "release-76-1" -> ICU_VERSION="76.1"

Build Flags & Configuration

CMake Options

Option Type Default Purpose
HAKKA_JSON_BUILD_TESTS BOOL OFF Enable test suites
HAKKA_JSON_USE_SYSTEM_DEPS BOOL ON Prefer system packages
HAKKA_JSON_ENABLE_PROFILING BOOL OFF Add -pg for gprof
HAKKA_JSON_ENABLE_TBB BOOL OFF Enable parallel STL
ICU_VERSION STRING Auto Specific ICU version
ICU_ROOT PATH "" Pre-installed ICU path
ICU_MSBUILD_PATH PATH Auto MSBuild.exe location
ICU_ARCH STRING x64 Windows architecture

Build Configurations

Configuration Purpose Characteristics
Debug Development, testing Sanitizers (Unix), debug symbols, assertions enabled
Release Production deployment Maximum optimization (-O3/O2), assertions disabled
RelWithDebInfo Profiling, debugging production Optimization + debug symbols
MinSizeRel Embedded systems Size optimization (-Os/O1)

Platform Variations:

  • Unix (GCC/Clang): Address/UB/Leak sanitizers in Debug, -O3 in Release
  • macOS (AppleClang): No sanitizers (compatibility), -O3 in Release
  • Windows (MSVC): Debug runtime (/MDd), /O2 in Release

Platform Architecture

Binary Format Variations

Platform Static Library Shared Library Executable
Linux .a .so (no extension)
macOS .a .dylib (no extension)
Windows .lib .dll + .lib (import) .exe

Platform-Specific Build Components

Linux:

  • Full sanitizer support
  • Alternative linkers (mold, gold, lld)
  • ICU: autoconf-based build
  • Explicit atomic library linking (GCC)

macOS:

  • Limited sanitizer support (AppleClang compatibility)
  • ICU: autoconf-based build
  • Framework-style dylib naming

Windows: - MSVC toolchain primary, clang-cl secondary - ICU: MSBuild-based build - CRT consistency requirements (gtest) - DLL export/import mechanics

Build Artifact Topology

Installation Structure

install/
├── include/          (Public API headers)
├── lib/              (Static + shared libraries)
├── bin/              (Executables, Windows DLLs)
└── share/licenses/   (License files)

Target Output Locations

Target Build Output Install Location
hakka_json_core build/src/ lib/
hakka_json build/capi/ lib/ (Unix), bin/ (Windows DLLs)
Test executables build/tests/{core,capi}/ Not installed
Benchmarks build/tests/perf/ bin/perf/
ICU libraries build/icu-install/lib/ Private (embedded)

Post-Build Copy: All libraries copied to target/release/ for convenience

Architectural Design Rationale

Target Type Selection

Static Core Library:

  • Enables link-time optimization across translation units
  • Allows consumers to choose static or shared linking
  • Prevents ABI fragmentation issues
  • Simplifies symbol visibility management

Shared C API Library:

  • Required for FFI (foreign function interface) compatibility
  • Enables hot-swapping in language bindings
  • Explicit C ABI boundary prevents C++ mangling issues
  • Facilitates versioning and dynamic updates

Interface Compiler Options:

  • Zero runtime overhead (header-only configuration)
  • Consistent flags across all targets
  • Platform-specific handling via generator expressions
  • Single source of truth for build configuration

Dependency Isolation Strategy

Public Dependencies (exposed in API):

  • Header-only libraries only (nlohmann_json, tl::expected)
  • No binary dependencies in public interface
  • Prevents consumer dependency conflicts

Private Dependencies (hidden from consumers):

  • All compiled libraries (ICU, atomic, TBB)
  • Platform-specific runtime requirements
  • Allows internal optimization without ABI impact

ICU Build Strategy

ExternalProject Integration:

  • Automatic download and build on first configuration
  • Cached artifacts reused on subsequent builds
  • Supports pre-installed ICU via ICU_ROOT
  • Platform-specific build commands (autoconf vs MSBuild)

Rationale:

  • ICU unavailable/outdated on many systems
  • Complex build requirements across platforms
  • Large dependency (>50MB) benefits from caching
  • Static linking with embedded data simplifies deployment

Summary

Build System Architecture

+---------------------------------------------------------------+
|                    Build System Layers                        |
+---------------------------------------------------------------+
| Configuration Layer:                                          |
|   - CMake options (HAKKA_JSON_*)                              |
|   - Build configurations (Debug/Release/...)                  |
|   - Platform detection and toolchain setup                    |
+---------------------------------------------------------------+
| Dependency Layer:                                             |
|   - Header-only: nlohmann_json, tl::expected (PUBLIC)         |
|   - Compiled: ICU, atomic, TBB (PRIVATE)                      |
|   - Testing: GoogleTest (PRIVATE, conditional)                |
+---------------------------------------------------------------+
| Target Layer:                                                 |
|   - STATIC: hakka_json_core                                   |
|   - SHARED: hakka_json (C API)                                |
|   - INTERFACE: compiler_options                               |
|   - EXECUTABLE: tests, benchmarks                             |
+---------------------------------------------------------------+
| Output Layer:                                                 |
|   - Build artifacts: .a/.lib, .so/.dll/.dylib                 |
|   - Installation: include/, lib/, bin/, share/                |
+---------------------------------------------------------------+

Architectural Principles

Dependency Management:

  • PUBLIC dependencies are header-only (zero ABI impact)
  • PRIVATE dependencies are statically linked (deployment simplicity)
  • Two-phase resolution (system packages → auto-download)

Target Design:

  • Static core enables consumer flexibility
  • Shared C API provides stable FFI boundary
  • Interface library centralizes configuration

Platform Strategy:

  • Common CMake logic for all platforms
  • Platform-specific variations isolated via generator expressions
  • Consistent behavior through compiler options interface

Build Workflow:

  1. Configure: Detect platform, resolve dependencies
  2. Generate: Create build system (Ninja/Make/MSBuild)
  3. Build: Compile targets with platform-specific flags
  4. Test: Execute test suites (if enabled)
  5. Install: Deploy to standard layout

Key Design Invariants

  1. Layered Dependencies: Core → C API → Tests (acyclic)
  2. ABI Stability: Only C API exposed for FFI, C++ internal
  3. Build Hermeticity: Self-contained builds via FetchContent/ExternalProject
  4. Platform Parity: Identical functionality across Linux/macOS/Windows
  5. Configuration Transparency: All options explicit, no hidden defaults
